Material support PU TPU PE PVC conveyor belt automobile and tyre industry use

Material support PU TPU PE PVC conveyor belt automobile and tyre industry use

  • Material support PU TPU PE PVC conveyor belt automobile and tyre industry use
  • Material support PU TPU PE PVC conveyor belt automobile and tyre industry use
  • Material support PU TPU PE PVC conveyor belt automobile and tyre industry use
  • Material support PU TPU PE PVC conveyor belt automobile and tyre industry use
  • Material support PU TPU PE PVC conveyor belt automobile and tyre industry use
Material support PU TPU PE PVC conveyor belt automobile and tyre industry use
Product Details:
Place of Origin: China
Brand Name: skypro
Certification: SGS/RoHs
Model Number: SP32-07
Payment & Shipping Terms:
Minimum Order Quantity: 200.sqm
Price: negotiable
Packaging Details: rolls,inner foam+ outer abrasion resistant canvas with hard cardboard tube inside
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 sq.m/day
Contact Now
Detailed Product Description
Features: Oil-resistant,anti-static Material: PVC,PU,TPU, PE, TPEE, Teflon, Silicone
Structure: Flat Belt Conditions: New
Colors: Green,Black,White,Blue And Other
High Light:

PVC PU conveyor belt

,

plastic conveyor belt



Conveyor / transfer belt for auto tire industry



Our company designs and produces cut-resistant conveyor belt according to characters of parts and components conveying on the high-speed press line of auto industry.

Such type of conveyor belt uses specially treated polyester fiber woven fabric as bearing skeleton, one side or both sides coated with PVC or PU as conveying side or composed with carpet fabric.

Such type of conveyor(transfer) belt features high strength, low elongation, good elasticity, wide working temperature, stable running, long durability.etc. The extraordinary property is it’s high tensile strength with cut resistance, impact resistance, which become the idea complement products of auto part press lines.



Model: SM25

Thickness:4.0mm

Tensile force for 1% elongation:10N/mm

Minimum pulley diameter:100mm

Maximum production width: 2000mm



Model: SU22-26P

Thickness:4.0mm

Tensile force for 1% elongation:12N/mm

Minimum pulley diameter:100mm

Maximum production width: 2000mm



Model: SP32-07

Thickness:2.8mm

Tensile force for 1% elongation:13N/mm

Minimum pulley diameter:100mm

Maximum production width: 3000mm



Model: SP42-14

Thickness:4.0mm

Tensile force for 1% elongation:16N/mm

Minimum pulley diameter:150mm

Maximum production width: 3000mm



Model: SP32-14

Thickness:2.8mm

Tensile force for 1% elongation:13N/mm

Minimum pulley diameter:100mm

Maximum production width: 3000mm



Model: SP22-07B

Thickness:1.3mm

Tensile force for 1% elongation:8N/mm

Minimum pulley diameter:250mm

Maximum production width: 3000mm

Model: SP22-07

Thickness:2.8mm

Tensile force for 1% elongation:8N/mm

Minimum pulley diameter:100mm

Maximum production width: 3000mm
