Name: Industrial PVC Conveyor Belt with Grid Pattern Flat Wood Making Sanding Machine Customizable OEM Options
Brand: Nanjing Skypro Rubber&Plastic Co.,ltd
SKU: SP22-56
Price: 15,000.00 USD
Availability: InStock

Home Products PVC Conveyor Belt

Industrial PVC Conveyor Belt with Grid Pattern Flat Wood Making Sanding Machine Customizable OEM Options

Product Details:

Place of Origin:	China
Brand Name:	Skypro
Certification:	ROHS/Reach/SGS
Model Number:	SP22-56

Payment & Shipping Terms:

Minimum Order Quantity:	200.sqm
Price:	negotiable
Packaging Details:	olls,inner foam+ outer abrasion resistant canvas with hard cardboard tube inside
Delivery Time:	15days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	5000 sq.m/day

Contact Now

Detailed Product Description

Name:	PVC Conveyor Belt	Pattern:	Glossy, Diamond, Rough Top,matt,etc
Condition:	New	Working Temperature:	-10/+80℃
Feature:	Anti-static, Softer, Fire-resistant,cold-resistant,oil-resistant.etc	Application:	Food, Tobacco, Electronic, Etc
Highlight:	industrial PVC conveyor belt with grid , customizable PVC conveyor belt for wood , flat sanding machine conveyor belt

Industrial PVC Conveyor Belt with Grid Pattern Flat Wood Making Sanding Machine Customizable OEM Options

High-quality PVC conveyor belt specifically designed for food processing applications including beans and candy transportation.

Specification

Product name:

PVC Conveyor Belt with Grid Pattern

Product Patterns:

Flat, Grass, Golf, Diamond, Matte surface finish, Small round particles and etc.

Product structure

Two plies cloth two plies pvc

Color

Black

Fiber layers

2 plies

Fiber class

Laterial stability polyester

Surface material

PVC

Surface pattern

Golf

Bottom material

Conductive polyester textile

Technical index

Total thickness	2.1mm
Surface coated thickness	0.7mm
Weight	2.3kg/m2
Maximum width	2000mm
Elongation 1% force	8N/mm
Tensile strengh	160N/mm
Hardness shore A	75
Working temrature	-10~+90℃
Minimum drum diameter	25mm
Lateral stability	Yes

Note

white, black, green, dark green, transparent, grey and all the colors at your request

Features

Low Noise, Flame Retardant
High Abrasion Resistance
Plasticizer Free
Excellent Matching Printing

Advantages

High strength, thin belt body, light weight
Soft belt body into a good groove, good elasticity
Impact resistance, wear resistance, corrosion resistance
Applied in larger load, faster speed and long-distance transport of materials
Smoothly motion, no deviation

Packing and Transportation

Packing Method	Rolled or flat sheet, 50-100kg/roll or custom packaging
Packing Material	Inner PE film + outer woven plastic bags (palletized optional)
Shipping Marks	Neutral packing with printed marks
Delivery Time	15 days after PO confirmation and payment
Freight Options	Sea (FCL & LCL) or air freight
Custom Services	Special size cutting and additional lamination available

Frequently Asked Questions

What is your company's capability?
Skypro is a professional rubber sheet manufacturer with over 20 years experience, ranking among China's top 10 rubber factories.

What is your annual production capacity?
We produce more than 18,000 tons of rubber sheet products annually.

How can I get samples?
We provide free samples with new clients responsible for delivery costs, which are deductible from formal orders. Our rubber products are ROHS/SGS certified and free of heavy metals.
