| Place of Origin: | China |
| Brand Name: | skypro |
| Certification: | SGS/RoHs |
| Model Number: | SP42-14 |
| Minimum Order Quantity: | 200.sqm |
|---|---|
| Price: | negotiable |
| Packaging Details: | rolls,inner foam+ outer abrasion resistant canvas with hard cardboard tube inside |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000 sq.m/day |
| Features: | Wear Resistant,high Tensile Strength,low Noise | Material: | PVC,PU,TPU, PE, TPEE, PTFE, Silicone |
|---|---|---|---|
| Structure: | Flat Grip Belt | Conditions: | New |
| Colors: | Green,Black,White,Blue And Other | Width: | 3.4m Max. |
| High Light: | PVC PU conveyor belt,plastic conveyor belt |
||
Conveyor belt for wood processing industry
The light duty conveyor belt we provide for wood processing industry can be widely used for artificial wood (high, middle density board, plywood, fiberboard, shaving board, composition board etc.),flooring production line as well as variety of mechanical equipments.
The different material, thickness and texture defines the adhesion, physical ,chemical and mechanical property. Meanwhile, the difference of textile material quality greatly decides the application range of the belt.
We use wear resistant surface coated belt to enable durable on surface, and use high strength textile fibers to reinforce the stability and strength of the belt.
Due to the specialty of belt structure, it come up with a lot of excellent property such like low stretch, dimensional stability, low noise and long durability.
Conveyor belt for wood processing industry
Model: SP39-76
Total thickness:5.5mm
Top coating thickness:2.0mm
Color: deep aquamarine
urface finish: plain flat (shiny or matt ) ,chevron, rough, diamond, rib, grid etc.
Weight:6.8kg/m2
Tensile force for 1% elongation:45N/mm
Top hardness:75 Shore A
Minimum pulley diameter:250mm
Maximum production width: 2800mm
Suitable machine type: pre-pressing machine
Model: SP42-14
Total thickness:5.5mm
Top coating thickness:1.0mm
Color: green
Weight:5.5kg/m2
Tensile force for 1% elongation:25N/mm
Top hardness:75 Shore A
Minimum pulley diameter:150mm
Maximum production width: 3000mm
Suitable machine type: pre-pressing machine
Model: SP32-36/13
Total thickness:9.5mm
Top coating thickness:6.0mm
Color: blue
Weight:8.5kg/m2
Top hardness:75 Shore A
Tensile force for 1% elongation:15N/mm
Minimum pulley diameter:120mm
Maximum production width: 2000mm
Suitable machine type: polishing machine
Model: SP32-36/28
Total thickness:9.0mm
Top coating thickness:5.5
Color: black
Weight: 8.9kg/m2
Top hardness:55 Shore A
Tensile force for 1% elongation:15N/mm
Minimum pulley diameter:120mm
Maximum production width: 2000mm
Suitable machine type: polishing machine
Model: SP22-46/14HD
Total thickness:5.5mm
Top coating thickness:3.5mm
Color: grey
Weight: 5.2kg/m2
Top hardness:65 Shore A
Tensile force for 1% elongation:10N/mm
Minimum pulley diameter:100mm
Maximum production width: 2000mm
Suitable machine type: polishing machine
Model: SP32-36/13
Total thickness:9.5mm
Top coating thickness:6.0mm
Color: black
Weight: 8.5kg/m2
Top hardness:50 Shore A
Tensile force for 1% elongation:15N/mm
Minimum pulley diameter:120mm
Maximum production width: 2000mm
Suitable machine type: polishing machine
Model: SP22-76/3D
Total thickness:5.0mm
Top coating thickness:3.5mm
Color: deep aquamarine
Weight: 5.2kg/m2
Top hardness:55 Shore A
Tensile force for 1% elongation:10N/mm
Minimum pulley diameter:50mm
Maximum production width: 2000mm
Suitable machine type: polishing machine
Model: SP25-14BA
Total thickness:1.6mm
Top coating thickness:0.3mm
Color: green
Weight: 1.6kg/m2
Top hardness:75 Shore A
Tensile force for 1% elongation:8N/mm
Minimum pulley diameter:20mm
Maximum production width: 3000mm
Model: SP25-74/0
Total thickness:2.0mm
Top coating thickness:0.5mm
Color: deep aquamarine
Weight: 2.3kg/m2
Top hardness:75 Shore A
Tensile force for 1% elongation:8N/mm
Minimum pulley diameter:25mm
Maximum production width: 3000mm
